Product Center
Broiler chicken floor-raising equipment
Features of the Broiler Feeding Line:
● Feed bins and hoppers: 100L capacity, galvanized steel.
● Feeding system: φ45 galvanized pipe, 4 holes/3 meters, imported South African auger.
● Drive system: Split-type reducer, 0.75kW 380V 50Hz.
● Sensors: Imported DOL products, stable performance and high sensitivity.
● Lifting system: Includes winch, pulleys, wire rope, wire rope clamps, and fixing materials. The winch lifting system allows for timely adjustment of the feed line height to meet the dietary height requirements of chickens at different ages.
Parameters
Product Introduction
Our Broiler Chicken Floor-Raising Equipment is a modern poultry farming solution designed for large-scale broiler production. The system provides a well-structured floor rearing environment combined with automatic feeding, nipple drinking, ventilation, lighting, and manure management systems to ensure optimal growth conditions for broiler chickens from day-old chicks to market weight.
Unlike traditional open-floor farming, this system improves space utilization, enhances biosecurity, reduces labor costs, and supports faster growth performance. It is widely used in commercial broiler farms, integrated poultry production companies, contract farming projects, and modern automated poultry houses worldwide.
Engineered for efficiency and durability, the system helps farmers achieve higher weight gain, better feed conversion ratios, and consistent flock performance while maintaining low operational costs.
Product Details
 |  |  |  |
| Tray | Feed brooder | Drive motor | Waterline pressure regulator |
Broiler Feed Tray Features:
● Rotary adjuster allows for easy and convenient adjustment of 7 feed levels, ensuring more even feeding and preventing sudden changes in feed level, resulting in greater stability and reliability.
● Adjustable switch controls feed speed or shuts off the feed tray. Seven wing plates at the bottom of the feed hopper prevent lateral feed throwing and spillage during pecking, reducing feed waste.
● Flat, slightly angled tray bottom ensures smoother feeding and even feed distribution.
● Four drainage holes on the tray bottom facilitate efficient water removal during cleaning.
● The tray bottom and grille use a simple screw-on fastening structure for a secure connection that facilitates maintenance and cleaning.
Applications
Our Broiler Chicken Floor-Raising Equipment is widely used in:
· Commercial Broiler Chicken Farms
· Integrated Poultry Production Projects
· Contract Broiler Farming Systems
· Large-Scale Poultry Houses
· Government Agricultural Projects
· Modern Automated Poultry Farms
· Poultry Investment Projects
· Rural Poultry Development Programs
Complete Poultry Farm Solution
We provide full turnkey solutions for broiler farms, including:
· Broiler Chicken Floor-Raising Equipment
· Automatic Feeding System
· Nipple Drinking System
· Ventilation System
· Cooling Pad System
· Heating System (optional)
· Lighting Control System
· Manure Removal System
· Feed Silo & Delivery System
· Poultry House Design & Layout Planning
· Installation Guidance
· Technical Training & After-Sales Support
Customized solutions are available based on farm capacity, climate conditions, and production targets.
FAQ
1.How many chickens can be raised in systems?
The capacity depends on the poultry house size . Our systems can support small farms as well as large commercial farms with tens of thousands of layers.
2.Is automatic egg collection available?
Yes. Our layer cage systems can be equipped with automatic egg collection systems to improve efficiency and reduce egg breakage.
3.What poultry equipment do you manufacture?
We manufacture a full range of poultry farming equipment, including layer cage systems, broiler cage systems, breeder farming equipment, feeding systems, drinking systems, ventilation systems, cooling pad systems, manure removal systems and environmental control systems.
4.Do you provide turnkey poultry farm solutions?
Yes. We provide complete turnkey poultry farm solutions, including poultry house design, equipment manufacturing, installation guidance and technical support.
5.Which countries do you export to?
Our poultry equipment has been exported to Africa, Southeast Asia, the Middle East and South America, including Nigeria, Kenya, Uganda, Indonesia, Philippines and many other countries.
6.Can you customize poultry equipment?
Yes. We provide customized poultry farming equipment solutions according to farm size, climate conditions and customer requirements.
